1.15PPM Bilge Water Alarm
2.Measuring range: 0-30ppm (display range 0-80ppm).
3.Display type : LED digital tube.
15PPM Bilge Water Alarm
1) Measuring range: 0-30ppm (display range 0-80ppm).
2) Measurement precision: (15ppm alarm) ± 5ppm (meet the IMO standard).
3) Display type : LED digital tube.
4) 15ppm bilge water Alarm Alarm indication: 4 red LED.
5) 2-way alarm relay.
6) Rated capacity of relay contact 250VAC 3A (non-emotional).
7)Model:15ppm bilge alarm.
15ppm Bilge Water Alarm Main performance indicators:
1) Measuring range: 0-30ppm (display range 0-80ppm)
2) Measurement precision: (15ppm alarm) ± 5ppm (meet the IMO standard)
3) Display type : LED digital tube
4) 15ppm bilge water Alarm Alarm indication: 4 red LED
5) 2-way alarm relay
6) Rated capacity of relay contact 250VAC 3A (non-emotional)
7) 15ppm bilge water Alarm Response time ≤ 5 seconds
8) Output signal 4-20mA
9) Environment temperature 0 - 55 Celsius degree
10) bilge water Alarm Relative humidity≤ 93%
11) Sample liquid temperature 1 - 55Celsius degree
12) Sample liquid pressure 0.1-0.6MPa
13) Sample liquid flow of 0.1-4L / min
14) Protection class IP55
15) Main power supply 220/110VAC 50Hz/60Hz
16) Power Consumption ≤ 20VA
17) Overall dimension 400mm × 300mm × 160mm
18) Meet the standard IMO. Res. MEPC. 107 (49) resolution
China Deyuan Marine Fitting Co.ltd is a professional supplier of marine equipment,such as 15ppm bilge separator,15ppm oily water separator,15ppm bilge alarm,oil content meter,marine sewage treatment plant etc.Pls contact us for more details if you are interested.
