DEYUAN
220M Three Strand Marine Nylon Rope/Mooring rope
1.Material:Polyamide/Nylon.
2.Structure:3 strand.
3.Twist.
4.Colour:White.
5.Size:8mm---40mm.
6.Length:200M/220M.
Marine nylon mooring rope
China Deyuan Marine Fitting Co.,ltd are leading supplier of marine mooring rope.Pls contact us for more details.
200m | Breaking strength(kn) | 220mm | ||||
Size | Weight (kgs)coil | Size | ||||
CIR (inch) | Dia (mm) | CIR (inch) | DIA (mm) | Weight Kgs coil | ||
1 | 8 | 7.7 | 14.7 | 1 | 8 | 8.5 |
1-1/8 | 9 | 9.8 | 17.7 | 1-1/8 | 9 | 10.8 |
1-1/4 | 10 | 12.1 | 21.6 | 1-1/4 | 10 | 13.3 |
1-1/2 | 12 | 17.7 | 29.4 | 1-1/2 | 12 | 19.5 |
1-3/4 | 14 | 24.1 | 39.2 | 1-3/4 | 14 | 26.5 |
2 | 16 | 31.0 | 50.0 | 2 | 16 | 34.1 |
2-1/4 | 18 | 39.2 | 61.8 | 2-1/4 | 18 | 43.1 |
2-1/2 | 20 | 48.5 | 75.5 | 2-1/2 | 20 | 53.4 |
2-3/4 | 22 | 58.5 | 90.2 | 2-3/4 | 22 | 64.4 |

|
