Marine Double quick release mooring hook

Specifications

Mooring towing hook:
1. Durable, long lifetime.
2. Warranty period: 12 Months.
3. Excellent quality and fair price
4.SWL:150

Mooring towing hook:

Marine Double quick release mooring hook:

Feature:



1. Durable, long lifetime.

2. Warranty period: 12 Months.

3. Excellent quality and fair price

Material:hook body:quality alloy.

Quick release hook will be entirely sprayed with zinc and the thickness.
Supply Scope:Single QRH.Double QRK, Triple QRH,Quadruple QRH and Six QRH.

Main technical hook:

pull of hook body for one unit:                    350-2500KN

quantity of hook body for one handle:         2 hooks

operating force by handle:                        <150N

swing angle of hook body in horizontal:      45~90⁰

swing angle of hook body in vertical:           45⁰

puling speed of electric capstan:                 18~25m/min

pull of electric capstan:                               10KN~30KN

working diameter of capstan:                      250mm

Capstan

Nominal pull: 1500 kg

Max pull : 3000 kgs

Hauling in speed: 20-30 Metres/min

Motor

Motor Type: ABB (Drawing attached)

Motor Capacity:7.5KW AT±1500 RPM

Power supply: 415V.3 Phase 50HZ

Insulation Class: F

Protection: IP65

Motor started: EX II 2 GD EExd-IIB-T4

Reversible with integrated brake

ATEX Certified

Starter/Foot Switch

Foot Switch Explosion proof grade: EX II 2 GD EExd-IIB-T4/ EX II 2GD EExd-IIC-1

Protection: IP65

ATEX Certified

Standard Coating:

One Layer Epoxy Zinc D.F.T. 40mu. And One Layer Epoxy (Black) D.F.T. 200mu., After Shot blasting to SA2.5

Material:

Hook:ZG35CrMo, Hook Housing:Q345B, All Axis Pin:40Cr,Foundation Bed:Q345B, Basic Material:35#,

Rope guide: stainless SS316 without painting.

Scope of Product Supply:

Complete equipment including hooks, Frame for hook, Steel structure for Motor and Gear Motor, Capstan, Foot switch, Control Panel, Holding Down Bolts and Template

Scope of Certificate and Report Supply:

ABS Certificate ,Inspection Release Note, Certificate of Conformity, Test and Inspection Plan, WPS, PQR, Welder Qualifications, Weld Map, NDT Report, Operator Qualification, Material Certificate, Dimensional Report, FAT Report, Motor Certificate Paint Inspection Report

Certificate:CCS,ABS,BV,DNV,GL

Also,We could produce as clients draiwng or do OEM

Available type:

Manual release spring towing hook

Pneumatic control spring towing hook

Manual release disc type towing hook

Pneumatic control disc type towing hook

Manual release harbour type towing hook

Pneumatic control harbour type towing hook

Single hook assembly

Double hook assembly

Triple hook assembly

Quardruple hook assembly

Pelican hook



Double quick release mooring hook
Product No.	S.W.L.	Cap.	Wt.	A	B	BB	C	D	E	EE	F	G	H	K	R	X
DHA-001	400	800	491	583	650	700	260	54	235	260	35	370	1233	96	90	6*M48
DHA-002	600	1200	878	788	750	780	290	62	275	290	45	407	1536	130	130	6*M56
DHA-003	750	1500	1049	888	750	850	325	70	275	325	45	417	1638	130	130	6*M64
DHA-004	1000	2000	1439	959	750	925	363	78	275	363	50	447	1709	150	150	6*M72
DHA-005	1250	2500	1602	1030	750	925	363	86	275	363	55	479	1780	150	150	6*M80
DHA-006	1500	3000	2332	1210	750	1000	400	86	275	400	55	499	1960	50	150	7*M80
