Marine Integrated Propeller and Rudder System

  • DEYUAN

Marine Rudder Propeller





Marine Rudder Propeller

Advantages

1.Maximum manoeuvrability.

2.Optimum efficiency.

3.Economical operation.

4.Space-saving installation.

5.Simple maintenance.

6.High reliability.

7.Optimized in terms of cavitation and vibration.

8.Dependable design.

9.Fixed or controllable-pitch propeller.







Type

Input power Max.(KW)

Input speed

rated.(rpm)

Input torque

max.(N.m)

Propeller Dia.max.

(mm)

Reduction ratio

Weight(kg)

SRP12

45

2300

200

500

1.93

65

SRP45

100

2500

450

800

2.5

190

SRP85

210

2350

850

950

2.68

400

SRP138

260

2000

1380

1100

3.01

1200

SRP180A

340

1800

1800

1150

3.46

1450

SRP180B

280

1500

1800

1150

2.88

1450

SRP180C

180

1000

1800

1150

2.526

1450

SRP226

350

1800

2260

1350

3.34

2000

SRP280

480

1800

2800

1350

3.96

2100

SRP310A

580

1800

3070

1550

3.718

2500
