Marine Single Quick Release Mooring Hook

Specifications

Single hook :
1. Durable, long lifetime.
2. Warranty period: 12 Months.
3. Excellent quality and fair price
4.SWL:150KN to 1

Single hook :

Marine Single quick release mooring hook:

Feature:

1. Durable, long lifetime.

2. Warranty period: 12 Months.

3. Excellent quality and fair price

Material:hook body:quality alloy.
Quick release hook will be entirely sprayed with zinc and the thickness.

Main technical hook:

pull of hook body for one unit:                    350-2500KN

quantity of hook body for one handle:         1 hook

operating force by handle:                        <150N

swing angle of hook body in horizontal:      45~90⁰

swing angle of hook body in vertical:           45⁰

puling speed of electric capstan:                18~25m/min

pull of electric capstan:                              10KN~30KN

working diameter of capstan:                      250mm

Capstan

Nominal pull: 1500 kgs

Max pull : 3000 kgs

Hauling in speed: 20-30 Metres/min

Motor

Motor Type: ABB (Drawing attached)

Motor Capacity:7.5KW AT±1500 RPM

Power supply: 415V.3 Phase 50HZ

Insulation Class: F

Protection: IP65

Motor started: EX II 2 GD EExd-IIB-T4

Reversible with integrated brake

ATEX Certified

Starter/Foot Switch:

Foot Switch Explosion proof grade: EX II 2 GD EExd-IIB-T4/ EX II 2GD EExd-IIC-1

Protection: IPATEX Certified

Standard Coating

One  Layer Epoxy Zinc D.F.T. 40mu. And One  Layer Epoxy (Black) D.F.T. 200mu., After Shot blasting to SA2.5.

Material

Hook:ZG35CrMo, Hook Housing:Q345B, All Axis Pin:40Cr,Foundation Bed:Q345B, Basic Material:35#,

Rope guide: stainless SS316 without painting.

Scope of Product Supply

Complete equipment including hooks, Frame for hook, Steel structure for Motor and Gear Motor, Capstan, Foot switch, Control Panel, Holding Down Bolts and Template

Scope of Certificate and Report Supply

ABS Certificate ,Inspection Release Note, Certificate of Conformity, Test and Inspection Plan, WPS, PQR, Welder Qualifications, Weld Map, NDT Report, Operator Qualification, Material Certificate, Dimensional Report, FAT Report, Motor Certificate Paint Inspection Report

Certificate:CCS,ABS,BV,DNV,GL

Available type:

Manual release spring towing hook

Pneumatic control spring towing hook

Manual release disc type towing hook

Pneumatic control disc type towing hook

Manual release harbour type towing hook

Pneumatic control harbour type towing hook

Single hook assembly

Double hook assembly

Triple hook assembly

Quardruple hook assembly

Pelican hook



Single quick release mooring hook
Product  No.	S.W.L.	Cap.	Wt.	A	B	BB	C	D	E	EE	F	G	H	K	R	X
SHA-001	400	400	304	668	600	600	225	54	225	225	35	370	1268	96	75	4*M48
SHA-002	600	600	512	873	650	650	235	54	235	200	45	407	1523	130	90	6*M48
SHA-003	750	750	587	923	650	650	225	62	225	200	45	417	1573	130	100	6*M56
SHA-004	1000	1000	792	1014	700	650	225	62	250	200	50	447	1714	150	100	6*M56
SHA-005	1250	1250	887	1085	700	650	225	70	250	200	55	479	1785	150	100	6*M64
SHA-006	1500	1500	1253	1255	700	650	225	78	250	195	55	499	1955	150	100	6*M72
