Free fall lifeboat launching device:
1.Class certificates:ABS, BV, CCS, DNV, EC, GL, LR, NK, RINA, KR etc.
2.SOLAS approval
Free fall lifeboat launching device:
Marine use Free fall lifeboat launching device :
This device can make lifeboat freely launch into water in an emergency or under the
circumstances of trim 20°and list 10°. Which meets the requirements of International
marine Safety of Life at Sea 1974, rules of international life saving equipments (LSA) and
IMO, MSC. 81(70) and other regulations.
| Model | Max. Safety working load | Max. hoisting load | Rope capacity of the reel | Hoisting speed | Hoisting speed wire rope |
| FH55 | 55KN | 42KN | 50M | ≥3m/min | φ20-18×19-1770 |
| FH65 | 65KN | 42KN | 50M/td> | ≥3m/min | φ20-18×19-1770 |
| FH150 | 150KN | 100KN | 110M | ≥3m/min | φ20-18×19-1770 |
| FH300 | 300KN | 190KN | 220M | ≥3m/min | φ20-18×19-1770 |
