PVC Fence:
The PVC fence is a simple, economical and effective containment boom. It is widely used on harbours,
rivers, lakes, ponds and other sites where there is a need to separate oils from water.
Features:
1.Made of the high strength fabric coated with the bright orange PVC, having high resistance to oil, seawater corrosion and UV radiation.
The solid float in the unique shape makes it more easily to storage. There is a force-withstanding element each in the upper and lower parts
of the boom body to ensure more strength. Elastic stiffeners are provided between solid floats to
keep the oil fence straight and stiff and ensure an effective draft.
2.The deployment and retrieval of the PVC fence is very simple. The oil fence can be supplied with the
hydraulically driven reel frame or the hanging rack.
Model Parameter | SWL450 | SWL750 | SWL900 | SWL1100 | |
Overall height(mm) | 450 | 750 | 900 | 1100 | |
Freeboard(mm) | 150 | 250 | 300 | 400 | |
Draft(mm) | 300 | 500 | 600 | 700 | |
Standard Length Per Section(m) | 10,20 | ||||
Tensile Strength (KN) | 20 | 30 | 40 | 45 | |
Ballast | Block or chain | ||||
Weight(Kg/m) | 3.1 | 4.2 | 5.2 | 5.8 | |
Storage rack for 60m | 2.8*1.7*0.7 | 2.8*1.7*1.0 | 2.8*1.7*1.2 | 2.8*1.7*1.4 |
