Ship Evacuation System

Single Chute Vertical Passage Marine Evacuation System



Single Chute Vertical Passage Marine Evacuation System

 We range of  Marine Evacuation Systems (MES), provide rapid and safe evacuation which delivers passengers and crew, dry-shod, directly into large capacity liferafts.

1.Evacuation capacity: 582 people in 30 minutes or 326 in 17 min 40 sec (HSC).

2.Installation heights from 10 to 22 metres.

3.Flexible and lightweight design.

4.Quick and simple mounting and dismounting for servicing.

5.Requires few crew members.

6.Complies with all international regulations.

7.Available with either A or B SOLAS emergency pack.

8.Liferafts manufactured to comply with requirements of SOLAS 74.
9.Prototype tested in accordance with EU Directive of Marine Equipment 96/98/EC and IMO Resolution A689(17) as amended.





Model	Maximum Stowage height (meter)	Maximum assigned  (person)	Capacity on the platform (person)	Weight (kg)	Dimension of container (mm)
MES-VP10.0-300	10	300	60	1360	2300×1600×2200
MES-VP11.0-300	11			1370
MES-VP12.0-300	12			1380
MES-VP13.0-300	13			1390
MES-VP14.0-300	14			1400
MES-VP15.0-300	15			1410
MES-VP16.0-300	16			1420
MES-VP17.0-300	17			1430
MES-VP18.0-300	18			1440
MES-VP19.0-300	19			1450
MES-VP20.0-300	20			1460
MES-VP21.0-300	21			1470
MES-VP22.0-300	22			1480
