Type RLS Hydraulic Crane For Sale

  • Deyuan Marine

Type RLS Hydraulic Crane For Sale

*Type RLS cranes are all electric-hydraulic drive

*The standard capacities are from 3t to 25t with outreaches up to 24m.

*Ship crane design is robust and solid, and components are chosen for a long life even in marine environment.

*As standard, crane is controlled from a platform above the slewing ring.


Type RLS ship crane


Basic design features

1:Welded box boom for low maintenance. The design is stiff and rigid,

with reduced flexibility, giving the operator a faster and more accurate positioning of the cargo.

2:Fail-safe brakes on all movements.

3:Fully enclosed and equipped drivers cabin with integrated heating.

4:Dual pump system with separate hydraulic circuit for hoist and luffing/slewing to ensure efficient cargo handling.

5:The variable speed hoist will automatically adjust to the highest possible speed for the appropriate load.


Standard equipmen

1:Complete crane with necessary equipment according to requirements

from specified Classification Society and Flag State to ensure safe operation.

2:Pedestal of standard height ready for mounting and welding to vessel’s main steel structure.

3:Electric starter equipment

4:Flood lights mounted on jib

5:Oil cooler for continuous use

6:Limit switches for automatic stop of hook travel in top and bottom position

7:Entire steel structure is made of certified steel and is sandblasted to Sa 2.5 prior to painting

8:Full two-component epoxy/acrylic paint system of highest marine standard. Color according to owner’s choic

9:All platforms and ladders are hot dip galvanized

10:Full set of documentation and Operation Manual

11:Hand operated pump for release of brake on winch and slewing gear

12:Spare filters for one year normal operation

Optional equipment

1:Remote control

2:Load indicator

3:Air conditioned cabin
