15 Persons Marine Use Throw Over Board Inflatable Life Raft

Specifications

Life Raft:
1.Certificate:CCS and EC.
2.SOLAS approved.
3.Open automatically.
4.material:fibre reinforced p

Life Raft :

15 Persons Marine Use Throw Over Board Inflatable Life Raft :

Feature:

1.Certificate:CCS.EC etc.

2.Reliable quality.

3.Open automatically.

4.material:fibre reinforced plastic.

The Throw-overboard Inflatable Liferafts are stored in containers on deck an inflate in the water when the painter line is pulled.

The standard sizes of the liferafts are available with:6,10,15,20 and 25 persons.

The liferafts with type approval by CCS and EC(EC was issued by GL).

15 persons Throw-over board Inflatable Life Raft:

Capacity:15 persons

The installation height is 18-50m from water surface.

Capacity:15 persons

Main dimension length:3546mm

Main dimension breadth:3425mm

(Co2+N2)*2/weight of gas:2800*2g

Max storage height:36M

Physical form: regular Twelve-sided polygon

Gross weight:135kg

The FRP container:Diameter 700X1460

Packaging size: 1420X740X780MM
