21KN Automatic release hook Lifeboat release hook automatic Release Hook

  • DEYUAN

 15KNHandle Release Hook

21KN Automatic Release Hook

Operation Instruction:
1.hoist hanging hook:take out the pin,pull the hook,Iet Spring housing and handle get to "hook" position.hoist the life when hook locked.
2.hoist releasing hook:when hook is loaded,pull the handle of spring housing with pin to "releasa" position,When hook is nonleaded,handle of spring housing can auromatically reach the " releasingn hook"position,then the life raft releases the hook.

Checking list
1.The junction between hook and pin shaft should be flexible.
2.Positions on the operating handle(hitching,releasing,discharging)should be exact and flesible.
3.The junction between roller and pin shaft should be flexible.

Maintaining and repairing:
After being used,the release hook should be checked periodically,all the moving parts should always being filled with enough grease:since some parts wore,bent,or the coutractility of spring cannot meet the requirement.the relesing motion not flexible or being locked deadly,then these relatingparts should be changed.

Periodical maintaining plan
The release hook must be checked every three months to ensue it's flexible and not being locked,so that it can be released smoothly when working.

Model

Specification



Release form

Safe working load



Test specification

Test load for 2.5 times

Test load for 6 times

On the pitch

Under the aperture

KN

KN

KN

KN

KN

MM

MM

DY

-T25

21

Automatic release

21

25

62.5

150

32

27

23

23

25

25
