Deyuan Marine
Anchor Chain Diameter: 36mm(AM2)
Anchoring deepth: Less than 82.5m
Working load: 55.1kn
Overload: 82.7kn
Holding Capacity: 329kn
Nominal speed: more than 9m/min
Hydraulic: HT3-2450C
Hydraulic motor: 63SCY14-1B
Motor model: Y225S-4, power: 37kw, 440v/60hz/3ph
Working pressure: 14.10Mpa
Flow rate: 77.68L/min
Remarks:
The distance between the two anchor lifter is 1830mm, can be adjusted by the client's requirement,
the mooring drum is available for the windlass on the client requirement.
