8 Man Throw Over Board Liferaft

Availability:
  • Deyuan Marine

8 Man Throw Over Board Liferaft

8 Man Throw Over Board Liferaft

Type: 6\8\10\12\15\16\20\25\30\35.

Suitable for installing in the vessels sailing on international voyages.

It meets the China MSA-“ Regulations for the Statutory Surveys of Ships and offshore Installations—Technical Regulations for the Statutory Surveys of Sea-going Ships Engaged inDomestic Voyages”2004,and it′s 2008 Amendments,Part4,

Ch.3.and SOLAS(74/96),LSA,MSC.81(70), MSC.226(82), MSC.218(82), MSC.293(87),ISO15738(2002).

Max. Storage Height: 18~36m.

Equipment Outfit: SOLAS A\B PACK.

Certificates:CCS,GL.







 Type

6Man

8Man

Shape

Regular hexagon



Capacity (Persons)

6

8

Dimension(L×W×H)

2104×2104×1200

2390×2390×1250

Cylinder

4L×1

5L×1

Container dimension

    (mm)

SOLAS A PACK  (a×b)

1090×615

SOLAS B PACK  (a×b)

1045×545

Packaging dimension

    (mm)

SOLAS A PACK  (c×d×e)

1140×675×650

SOLAS B PACK  (c×d×e)

1100×600×590

Required bollard pull  (KN)

For 2knot speed

0.30

0.35

For 3knot speed

0.80

0.90

Weight   (kg)

78

90
