AC Vertical Windlass

  • Deyuan Marine

AC Vertical Windlass

AC Vertical windlass (3000W,4000W,5500W,7500W)

Stainless steel vertical windlass.Available in high or low profile, with different drives and  for boats up to 50m.The NYS windlass can use chains up to 18mm with stud link in diameter. Possibility of 230V,400V ,12V,24V .

Main parameter

AC Specification

Electric motor 3000W 4000W 5500W 7500W
Motor supply  12V/24V 230V/400V 230V/400V 230V/400V
Max. lift load 2500KG 3100KG 3500KG 3600KG
Working load 1400KG 1600KG 1700KG 1800KG
Line speed 15m/min 15m/min 15m/min 15m/min
Chain(DIN766) 12.5mm-13mm 14mm 16mm 18mm
生产图 02
