Anchor Chain diameter: 19mm(AM2)
Gypay diameter: 304mm
Working load: 15.3kn
Overload: 23.0kn
Support load: 126kn
Nominal speed: 9m/min
Max anchor weight: 660kg
Max anchoring deepth: 82.5m
Warping head load: 10kn
Speed: 9m/min
Working rope diameter: 30mm
Transmission ratio: 96.3
Transmission efficiency: 0.62
Motor model: JZ2-H33-4/12
Speed: 1450/500 rpm
power: 8.5/3.5kw
Voltage: 380v/50hz
Working: 30/10 min
