CWF-90/1Marine Vertical Low Pressure Silent Air Compressor

Inquire Add to Basket

  • New

  • Centrifugal, CVF Marine compressors

  • NO

  • Diesel

  • Lubricated

  • Yes

  • Guangdong, China (Mainland)

  • DEYUAN MARINE

  • CWF

  • 380 v

  • NO

  • 300KG

  • CCS, RINA, KR ,BV etc.

  • one year

  • Overseas third-party support available

  • CCS, RINA, KR ,BV etc.

  • 500~1000r/min

  • 10~20M3/h.

  • standard export packing

  • 30-40days

CWF-90/1Marine Vertical Low Pressure Silent Air Compressor

CWF-90/1Marine Vertical Low Pressure Silent Air Compressor

1.Type: CWF-90/1Marine Vertical Low Pressure Air Compressor

2.Capacity:10~20M3/h.

3.Rotating speed:500~1000r/min.

4.Certificate:CCS,RINA,KR,BV etc.

CWF-90/1 Marine vertical low pressure air compressor



Models

CVF-90/1

Number of cylinders

4

Bore(mm)

2*115+2*85

Stroke(mm)

116

Capacity (m3/h)

90

Rated pressure (Mpa)

1.0

Rated speed (r/min)

640

Method of lubrication

splash

Drive mode

Belt transmission
