Diesel Oil Separator units

Availability:

Marine Oil Separator





Marine Oil Separator

Marine separator is mainly used to remove water and mechanical impurities from fuel oil, lubricating oil and other mineral oil in marine diesel engine unit and land-used diesel generator unit of power station so as to reduce wear of the diesel engine and other machine, and prolong engine life. The model is also used to separate two unsolvable liquids with different specific gravity or remove small amount of solid particle from liquid.

The machine adopts automatic control, it has the advantages of high efficiency, low oil consumption, convenient operation and economic maintenance cost.

The clear oil and dirty water are pumped out by centripetal pump, the sludge is discharged automatically and fully.

The machine is one kind of rotary machine with high speed, After accurate dynamic balancing, it can run for long time with low vibration, safety and security.

The design, product and acceptance are conformed to the standard of GB/T5745 Marine Disc Separator.

Installation Notice:

1.Take into consideration the enough space available to maintenance and repair separator before installation.

2.The foundation must be firm, plan and leveling.

3.All the pipes connecting with separator should be flexible.

4.The operation water of the separator must be soft water, the pressure of which is between 0.025MPa and 0.03MPa.







Type

Max Capacity(L/h)

Motor Power(kW)

DYR203CD-23

1500

2.2

DYB202DD-21

1500

2.2

DYH204SD-23

2000

4

DYB302DD-21

2500

3

DYH304SD-23

3000

4

DYB203SD-21

3500

5.5

DYH206SD-23

4000

5.5

DYB204SD-21

4500

7.5

DYB205SD-21

6000

7.5

DYB207SD-21

8000

11

DYH509

10000

15

DYB409

14000

15

DYB211

20000

22
