Electric Anchor and Mooring Rope Capstan Winch with CCS Certificate

Electric anchor and mooring rope capstan winch with CCS Certificate

*  various sizes can be provided.
*  produce acc. to customer's drawings.
*  with ABS, BV, CCS ,DNV,RINA,KR,LR certificates.





Electric mooring rope capstan

We,China Deyuan marine fitting Co.,ltd ,can provide different types of electric warping hawser capstan and electric or

 hydraulic mooring capstan.Pls feel free to contact us for more details.



Size	Mooring load (KN)	Moorin speed (mm)	Wire rope dia. (mm)	Motor power (KW)
				electric	hydraulic
5KN	5	≥18	Φ11	3/1.2	5.5
10KN	10	≥18	Φ11	4.3/1.7	7.5
15KN	15	≥18	Φ13	8.5/3.5	11
20KN	20	≥18	Φ15	11/11/7.5	1.5
30KN	30	≥18	Φ17.5	16/16/11	18.5
50KN	50	≥18	Φ20.5	16	30
70KN	70	≥15	Φ26	22	45
100KN	100	≥15	Φ28	45/45/30	55
120KN	120	≥15	Φ32.5	60/60/45	75
150KN	150	≥15	Φ36.5	60/60/45	90
200KN	200	≥15	Φ40	75/75/36	110
250KN	250	≥12	Φ46	75/75/36	110
