Free Fall Lifeboat Used for Offshore Oil Drilling Units

Availability:
  • DEYUAN

Specifications

Free fall lifeboat


*Material:F.R.P .


*Certificate:CCS,EC,BV,ABS,BV.


*Capacity:3~61Person.


*Standard: ISO 9001:2000 and MED

F.R.P Totally Enclosed Free Fall Lifeboat





F.R.P Totally Enclosed Free Fall Lifeboat


The most popular series,F.R.P totally enclosed free fall lifeboat is developed from totally enclosed lifeboat.


The construction is specially strengthened to have light acceleration strike during water entry that can be completed


within seconds and escape rapidly from the vessels with longer self-stability.


The F.R.P totally enclosed free fall lifeboat suits particularly the more dangerous projects like offshore oil drilling


units etc.8models from 4.90 to 8.80M are available.







Model

Main DIM.

(M)

Capacity

(p)

Length of

Ramp(m)

Speed

(knots)

Drop height

(m)

Davit load

(kg)

DY-FN-4.90

4.90*2.25*0.86

16

5.90

>6

16

4040

DY-FN-4.90

4320

DY-FN-5.80

5.8*2.55*0.90

25

7.0

>6

17

5560

DY-FF-5.80

5890

DYM-FN-6.65

6.65*2.70*1.20

30

8.2

>6

21

6337

DYM-FF-6.65

6637

DY-FN-6.80

6.80*2.70*1.20

31

8.20

>6

22

6439.5

DY-FN-6.80

6739.50

DY-FN-7.50

7.50*2.70*1.20

35

9.0

>6

22

7374

DY-FF-7.50

7724

DY-FN-8.50

8.80*2.94*1.20

40

10.2

>6

25

8422

DY-FF-8.50

8722
