High Quality Double-deck Sport Light CXH2-101P

Availability:



1.The shell is made of high-strength engineering plastic PA+GF,the lampshade adopts injection of PC,lens hood adopts good quality stainless steel.

2.The signal lights have the whole seal structure,it is waterproof under the bad environment.

3.The connection of the signal light's lamp holder and the base adopt plug-in type,can replace the up and down bulb as open the cover.

4.The signal lights can work normally under the temperature -30℃~55



Double-deck sport light CXH2-101P

The scope of application:

Applied to the ships with the length 50m or above 50m as lamp signal liaison when night navigation

Product characteristic:

1.The shell is made of high-strength engineering plastic PA+GF,the lampshade adopts injection of PC,lens hood adopts good quality stainless steel.

2.The signal lights have the whole seal structure,it is waterproof under the bad environment.

3.The connection of the signal light's lamp holder and the base adopt plug-in type,can replace the up and down bulb as open the cover.

4.The signal lights can work normally under the temperature -30℃~55
Adopt standard:

1.Conform to the international regulations for preventings collision at sea,1972 and Grade entry norms for steel ships

2.Confirm to the international standard IEC60598-1-2008

3.Confirm to the standard of marine electric signal light's technical condition GB/T3028-1995

Production authentication:

1.Approved by CCS(China Classification society),and ZY of China Fishery Inspection.

2.Passed the authentication of CE

3.Approved by Germanischer Lloyd"GL"

4.Approved by MED/EC

Specification:

Name

type

Visibility

Level arc

Lamp holder

Bulb

Cable outside Diameter

Protection Class

Color

weight

Double-deck sport light

CXH2-101P

3n.m

112.5°

P28S

24V/2*60w60cd

110v/2*60w60cd

220v/2*65w60cd



Φ9

IP56

Red

4.15

kg
