Deyuan Marine
Hydraulic Combined Anchor Windlass
Electric Combined anchor windlass
China Deyuan Marine Fitting Co., Ltd is a professional supplier of marine deck equipment, we can offer marine hydraulic steering gear, anchor windlass, marine mooring rope capstan, marine winches. Class certificate such as CCS, ABS, DNV, BV, RINA are available, our products are in good quality with very compectitive price. If you are interested, pls feel free to contact us at any time.
Anchor Windlass Features:
1) Drive: Electric / hydraulic
2) Configuration: Single in vertical / horizontal arrangement / double Gypsies in horizontal
3) Chain size: 19 mm to 50 mm
4) Chain speed: Complying with ISO requirements
5) Clutch: Manually operated dog clutch
6) Brake: Manually and hydraulic operated band brake
Windlass winch, diesel anchor windlass, diesel windlass
| Name | Chain Dia (mm) | Working Load(KN) | Working Speed (m/min) | Mooring pull (KN) | Mooring Speed (m/min) | Drum Capacity (m) | Motor Power (kw) |
| Φ19/20.5/22 | 19/20.5/22 | 15.3/17.9/20.5 | ≥12 | 20 | ≥12 | Φ15*120 | 8.5/3.5 |
| Φ24/26/28 | 24/26/28 | 24.5/28.7/33.3 | ≥9 | 20 | ≥12 | Φ15*120 | 8.5/3.5 |
| Φ30 | 30 | 38.3 | ≥9 | 30 | ≥12 | Φ18*150 | 11/11/7.5 |
| Φ32/34/36 | 32/34/36 | 43.5/49.1/55.1 | ≥9 | 50 | ≥12 | Φ20.5*150 | 16/16/11 |
| Φ38/40/42 | 38/40/42 | 61.4/68.0/75 | ≥9 | 50 | ≥12 | Φ20.5*150 | 22/22/16 |
| Φ44/46/48 | 44/46/48 | 82.3/89.9/97.9 | ≥9 | 75 | ≥12 | Φ26*200 | 30/30/22 |
| Φ50/52/54 | 50/52/54 | 106.3/114.9/123.9 | ≥9 | 75 | ≥15 | Φ26*200 | 30/30/22 |
| Φ56/58/60 | 56/58/60 | 133.3/143.0/153 | ≥9 | 75 | ≥15 | Φ26*200 | 45/45/30 |
| Φ62/64 | 62/64 | 163.4/174.1 | ≥9 | 100 | ≥15 | Φ30*200 | 45/45/30 |
| Φ66/68/70 | 66/68/70 | 185.1/196.5 | ≥9 | 150 | ≥15 | Φ32.5*200 | 60/60/45 |
