Single Gypsy Anchor Windlass
Anchor Windlass Features:
1) Drive: Electric / hydraulic
2) Configuration: Single in vertical / horizontal arrangement / double
Gypsies in horizontal
3) Chain size: 19 mm to 50 mm
4) Chain speed: Complying with ISO requirements
5) Clutch: Manually operated dog clutch
6) Brake: Manually and hydraulic operated band brake
Name | Chain Dia(mm) | Working Load(KN) | Supporting load | Working Speed (m/min) | Warping load | Warping speed | Motor power |
| Φ14/16/17.5 Electric anchor windlass | 14/16/17.5 | 8.3/10.9/13 | 51/67/80 | ≥12 | 8 | 10 | 4.3/1.7 |
| Φ19/20/22.5 Electric anchor windlass | 19/20/22.5 | 15.3/17.9/20.6 | 95/110/126 | ≥12 | 10 | 10 | 8.5/3.5 |
| Φ24/26 Electric anchor windlass | 24/26 | 24.5/28.7 | 149/175 | ≥9 | 20 | 8.5 | 8.5 |
| Φ26/28 Electric anchor windlass | 26/28 | 28.7/33.3 | 175/202 | ≥9 | 20 | 8.5 | 11/11/7.5 |
| Φ28/30/32 Electric anchor windlass | 28/30/32 | 33.3/38.3/43.5 | 202/231/ 261 | ≥9 | 30 | 8.5 | 16/16/11 |
| Φ32/34/36 Electric anchor windlass | 32/34/36 | 43.5/49.1/55.1 | 261/294/ 329 | ≥9 | 30 | 8.5 | 16/16/11 |
| Φ32/34/36/38 Electric anchor windlass | 32/34/36/38 | 43.5/49.1/55.1/61.4 | 261/294/ 329/365 | ≥9 | 30 | 8.5 | 22/22/16 |
| Φ38/40/42 Electric anchor windlass | 38/40/42 | 61.4/68.0/ 75.0 | 365/402/442 | ≥9 | 50 | 8.5 | 22/22/16 |
| Φ42/44/46 Electric anchor windlass | 42/44/46 | 75.0/82.3/ 89.9 | 442/483/526 | ≥9 | 30 | 12 | 22/22/16 |
| Φ44/46/48 Electric anchor windlass | 44/46/48 | 82.3/89.9/ 97.9 | 483/526/ 570 | ≥9 | 30 | 12 | 30/30/22 |
| Φ50/52/54 Electric anchor windlass | 44/46/48 | 106.3/114.9/123.9 | 617/664/713 | ≥9 | 50 | 12 | 30/30/22 |
| Φ56/58/60 Electric anchor windlass | 56/58/60 | 133.3/143.0/153 | 761/816/870 | ≥9 | 50 | 14 | 45/45/30 |
| Φ62/64 Electric anchor windlass | 62/64 | 163.4/174.1 | 925/982 | ≥9 | 50 | 14 | 45/45/30 |
| Φ66/68 Electric anchor windlass | 66/68 | 185.1/196.5 | 1040/1098 | ≥9 | 50 | 14 | 45/45/30 |
| Φ70/73 Electric anchor windlass | 66/68 | 208.3/226.5 | 1160/1254 | ≥9 | 50 | 15 | 60/60/45 |
| Φ76/78 Electric anchor windlass | 66/68 | 245.5/258.6 | 1350/1416 | ≥9 | 50 | 15 | 60/60/45 |
