Marine diesel genset with CCS

  Deutz marine diesel genset



1.Rated speed/frequency:1500rpm/50HZ.

2.Continuour output:16kw/20KVA.

3.Standby output:18KW/22.5KVA.



16KW Deutz marine diesel genset

Genset features:

Rated speed/frequency:1500rpm/50HZ

Continuour output:16kw/20KVA

Standby output:18KW/22.5KVA

Voltage,phase and wire:400v/230v,3 phase and 4 wires

Rated power factor:0.8

Maximum output current:60(A)

Engine details:

Model:D226B-3D

Engine type:water-cooled,3cylinders in line,4stroke

Maximum output:31kw

Bore*stroke:105*120(mm)

Fuel consumption:6.5L/H(in full load)

Alternator details:

Excitation:brushless

Protection class:IP23

Efficiency:88%

Voltage adjust range:≥±6%

Steady state voltage regulation:≤±1%

Voltage control:AVR
