NS2587 chock:
1.Strict quality control.
2.Can issue BV,CCS,DNV,LR,KR,ABS,RINA certificate
3.Good after-sale serv
NS2587 chock:
NS2587 marine chocks:
Feature:
1.Strict quality control.
2.Can issue BV,CCS,DNV,LR,KR,ABS,RINA certificate
3.Material: ZG200-400,ZG230-450.
4.Paint: Grey Epoxy Primer or Black Bitumen Paint, also can do comply with your requirement for the thickness.
5. Packing: Steel Pallet
6.surface in contact with the rope in use been finished smoothly.
We designs and manufactures panama chocks in a wide variety of sizes and styles.
Our panama chocks and other deck fittings are used by military and industrial ships, operating effectively throughout the world.
Drawing:
NS2587 chock | |||||
Nominal size | c2 | d2 | e2 | t2 | Mass(kg) |
200*150 | 330 | 280 | 130 | 16 | 14.9 |
300*200 | 458 | 358 | 158 | 20 | 47 |
400*250 | 600 | 450 | 200 | 25 | 99 |
Also we can supply other kinds of Chocks as below.
Deck mounted Panama chock JIS F2017-1982 type AC
Bulwark mounted Panama Chock JIS F2017-1982 Type BC
Deck Mounted Closed Chock JIS F2005-1975
Bulwark mounted mooring chock JIS F 2007-1976 type A
Bulwark Mounted Chock DIN81915-1998 Type A
Bulwark Mounted Chock DIN81915-1998 Type B
Deck mounted Chock DIN81915-1998 type C
Deck mounted Chock DIN81915-1998 type D
Deck mounted Chock DIN81915-1998 type E
Bulwark Mounted Chock EU Type
Single Point Mooring Pipe JIS F 2030-1978 type A
Single Point Mooring Pipe JIS F 2030-1978 type B
Deck mounted chock type A NS2587
Deck mounted chock type B NS2587
Deck mounted chock type A NS2588
Deck mounted chock type B NS2588
Deck mounted chock type A NS2589
Deck mounted chock type B NS2589
Deck mounted chock type A NS2590
Deck mounted chock type B NS2590
Mooring chock CB34 -76 TYPE A
Mooring chock CB34 -76 TYPE C
Open chock JISF 2006 TYPE FC
