Ocean Safety Life raft SOLAS with 12 Person
Throw Over Board Liferaft
DEYUAN MARINE Life Rafts are packed in rugged deck mountable fiberglass containers.
Small profile, the DEYUAN MARINE life raft container remains secure and resistant to the harsh marine environment.
The DEYUAN MARINE line of rafts is manufactured using polyurethane coated nylon fabric and is high frequency welded for
added consistency and durability.
Compared to other life raft materials, urethane polymers are renowned for their abrasion and cold cracking resistance.
Additionally, this fabric is much less affected by hydrolysis, ozone, fuel and chemical attack.
Equipment Pack Contains:
• 2 Red Hand Flares (SOLAS)
• Bailer
• Topping-up Pump
• Signal Mirror
• Water Tight Flashlight
• Extra Flashlight Batteries
• Floating Knife
• Rescue Throwing Quoit
• Sponges
• Paddles
• Seasick Tablets
• Repair Kit
• Sea Anchor
• First Aid Kit
• Instruction Handbook
• Whistle
Type | 10Man | 12Man | ||
Shape | Regular octagon
| |||
Capacity (Persons) | 10 | 12 | ||
Dimension(L×W×H) | 2694×2694×1400 | 2924×2924×1500 | ||
Cylinder | 6L×1 | 7L×1 | ||
Container dimension (mm) | SOLAS A PACK (a×b) | 1260×645 | ||
SOLAS B PACK (a×b) | 1090×615 | |||
Packaging dimension (mm) | SOLAS A PACK (c×d×e) | 1330×715×700 | ||
SOLAS B PACK (c×d×e) | 1100×635×560 | |||
Required bollard pull (KN) | For 2knot speed | 0.40 | 0.45 | |
For 3knot speed | 0.90 | 0.95 | ||
Weight (kg) | ≤102 | ≤120 |
