Deyuan Marine
1.High quality
2.Fast delivery
3.Long life service
4.Competitive price
5.ABS, LR, BV, DNV,NK, CCS
YMAseries Electric anchor windlass
1.High quality
2.Fast delivery
3.Long life service
4.Competitive price
5.ABS, LR, BV, DNV,NK, CCS
Type illustration
the first letter: D-electric Y-hydraulic S-manual C-diesel engine
the letter M:anchor winch
the third letter: Type A,B,E
Main technical parameter
| Type | anchor chain diam | working load | over loading | loading support | nominal speed | mooring line load | |||
| (mm) | AM2 | AM3 | AM2 | AM3 | AM2 | AM3 | m/min | Kn | |
| YMA-17.5 | 17.5 | 13 | 14.6 | 19.5 | 21.9 | 80 | 115 | 9 | 8 |
| YMA-19 | 19 | 15.3 | 17.2 | 23 | 25.8 | 95 | 135 | 9 | 10 |
| YMA-20 | 20 | 17.9 | 20 | 26.9 | 30 | 110 | 157 | 9 | 10 |
| YMA-22 | 22 | 20.6 | 23 | 30.9 | 34.5 | 126 | 180 | 9 | 15 |
| YMA-24 | 24 | 24.5 | 27.4 | 36.8 | 41.1 | 149 | 214 | 9 | 20 |
| YMA-26 | 26 | 28.7 | 32.1 | 43.1 | 48.2 | 175 | 250 | 9 | 20 |
| YMA-28 | 28 | 33.3 | 37.2 | 50 | 55.8 | 202 | 289 | 9 | 20 |
| YMA-30 | 30 | 38.3 | 42.8 | 57.5 | 64.2 | 231 | 330 | 9 | 30 |
| YMA-32 | 32 | 43.5 | 48.6 | 65.3 | 72.9 | 261 | 374 | 9 | 30 |
| YMA-34 | 34 | 49.1 | 54.9 | 73.3 | 82.4 | 294 | 421 | 9 | 30 |
| YMA-36 | 36 | 55.1 | 61.6 | 82.7 | 92.4 | 329 | 470 | 9 | 30 |
| YMA-38 | 38 | 61.4 | 68.9 | 92.1 | 103.4 | 365 | 522 | 9 | 40 |
| YMA-40 | 40 | 68 | 76 | 102 | 114 | 402 | 576 | 9 | 40 |
| YMA-42 | 42 | 75 | 83.8 | 112.5 | 125.7 | 442 | 632 | 9 | 50 |
| YMA-44 | 44 | 82.3 | 92 | 123.5 | 138 | 483 | 691 | 9 | 50 |
| YMA-46 | 46 | 89.9 | 100.5 | 134.9 | 150.8 | 526 | 753 | 9 | 50 |
| YMA-48 | 48 | 97.9 | 109.4 | 146.9 | 164.1 | 570 | 816 | 9 | 50 |
| YMA-50 | 50 | 106.3 | 118.8 | 159.5 | 178.2 | 617 | 882 | 9 | 50 |
