Ballast Water Management System
Ballast Water Management System
DEYUAN MARINE Treatment Systems is a pioneer and market leader in provisioning large commercial ships with Ballast Water Treatment Systems (BWTS). DEYUAN MARINE enables its customers to cost-effectively comply with pending IMO and U.S. regulations that protect the world's oceans and waterways from invasive aquatic plants and animals. These harmful aquatic organisms are transferred from one ecosystem to another via the ballast water discharged by ships, which if left untreated, are known to cause devastating ecological and economic harm to their new environments.
The International Maritime Organization (IMO) has adopted a Ballast Water Management Convention which, upon ratification, will require all commercial ships to install and operate BWTS on a scheduled roll-out beginning in 2012. To address this critical requirement, DEYUAN MARINE developed, patented and commercialized the Ballast Water Management System, becoming the first-to-market with a Type Approved ballast water treatment system which fully complies with the IMO's Ballast Water Discharge Standards.
Model of System | Capacity (M3/H) | Power Consumption (Kw) | Footprint Area(M2) |
BWMS-300 | 100-300 | 27 | ~2.9 |
BWMS-500 | 300-500 | 42 | ~3.6 |
BWMS-700 | 500-700 | 54 | ~5.0 |
BWMS-900 | 700-900 | 84 | ~6.0 |
BWMS-1200 | 900-1200 | 96 | ~6.5 |
BWMS-1600 | 1200-1600 | 120 | ~7.0 |
*BWMS-900DS | 1600-1800 | 168 | ~12 |
*BWMS-1200DS | 1800-2400 | 192 | ~13 |
*BWMS-1600DS | 2400-3200 | 240 | ~14 |
Note: * Double system |
