10~250 Person Marine Sewage Treatment Plant RO Water Purifier
China Deyuan Marine Fitting Co. Ltd is a professional supplier of marine equipment, such as 15ppm bilge separator, 15ppm oily water separator, 15ppm bilge alarm, oil content meter, marine sewage treatment plant etc. Pls contact us for more details if you are interested.
Main Technical Table
| Model | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | 100 | 150 | 200 | 250 | |||
| Load | Average load L/d | 1190 | 1540 | 1890 | 2310 | 3080 | 3780 | 4480 | 6020 | 7700 | 11200 | 14700 | 18200 | ||
| Peak load L/h | 149 | 193 | 237 | 289 | 385 | 473 | 560 | 753 | 963 | 1400 | 1838 | 2275 | |||
| Organic load kgBOD5/d | 0.595 | 0.77 | 0.945 | 1.155 | 1.54 | 1.89 | 2.24 | 3.01 | 3.85 | 5.6 | 7.35 | 9.10 | |||
| Rated capacity(P) | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | 100 | 150 | 200 | 250 | |||
| Max capacity(P) | 17 | 22 | 27 | 33 | 44 | 54 | 64 | 86 | 110 | 160 | 210 | 260 | |||
| Electricity | AC380V, 50HZ, 3φ/AC 440, 60Hz, 3φ | ||||||||||||||
| Power(KW) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 2.0 | 2.0 | 2.5 | 2.5 | 3.0 | |||||
| External dimensions L*W*H(mm) | 1550× 1400× 1600 | 1650× 1400× 1600 | 1850× 1500× 1635 | 1950× 1500× 1635 | 1800× 1700× 1900 | 1900× 1700 1950 | 2100× 1700× 2000 | 2500× 1900× 2150 | 2500× 1900× 2300 | 3150× 2400× 2300 | |||||
| Weight | Dry weight (Kg) | 1150 | 1200 | 1250 | 1350 | 1500 | 1750 | 1950 | 2150 | 2900 | 3800 | ||||
| Wet weight (Kg) | 2600 | 2933 | 3210 | 3928 | 4689 | 5665 | 6486 | 8100 | 10400 | 14680 | |||||
| Discharge standard | TSS35mg/L, BOD525mg/L, COD125mg/L, Coli form100pcs/100ml, PH:68.5 | ||||||||||||||
More types of Marine Sewage Treatment Plants with competitive price can be offered, please contact us for more details.
