China (Mainland)
DEYUAN
WFCB series
Sewage treatment plant
Sewage treatment plant
Export standard packaging.
About 20 days
sewage biochemical treatment plant :
WFCB series domestic sewage biochemical treatment plant :
Feature:
1.CCS certificate.
2.suitable dimension,compact structure
3.light weight, flexible starting and running.
The plant is applicable to treat the sewage from the onboard ship toilets to meet international standards of discharge.
The plant adopts biomembrane contact oxidation method and sterilizing principle to digest organic pollutant.This plant has suitable dimension,compact structure and light weight,flexible starting and running.
The discharge water after treatment fullfil discharge standard requirement of international sea environment protection committee IMO MEPC. 2(VI).
As strong corrosion resistance,it can use seawater to flush sewage in toilets.
| Model parameter | WFCB10 | WFCB20 | WFCB30 | WFCB40 | WFCB50 | WFCB60 | WFCB80 | WFCB100 | WFCB150 | WFCB200 | WFCB250 | WFCB300 | |
| Number of adaptation | 10 | 20 | 30 | 40 | 50 | 60 | 80 | 100 | 150 | 200 | 250 | 300 | |
| Processing Load | Average l/p | 810 | 1540 | 2240 | 3080 | 3780 | 4480 | 5880 | 7410 | 10920 | 14640 | 18240 | 21700 |
| peak l/h | 105 | 193 | 280 | 385 | 470 | 560 | 735 | 928 | 1366 | 1830 | 2280 | 2712 | |
| organic load BOD5/d(KG) | 0.42 | 0.77 | 1.12 | 1.54 | 1.89 | 2.24 | 2.94 | 3.71 | 5.46 | 7.35 | 9.1 | 10.9 | |
| Crushing pump | model | 0.5CWF-10 | 1CWF-11 | 2CWF-11 | 3CWF-10 | ||||||||
| capacitym3/h | 5 | 10 | 20 | 30 | |||||||||
| lift m | 10 | 11 | 11 | 10 | |||||||||
| speed r/min | 2840 | 2840 | 2840 | 2890 | |||||||||
| motor power kw | 0.75 | 1.5 | 2.2 | 4 | |||||||||
| Air pump | model | CYBW-10 | CYBW-20 | CYBW-40 | CYBW-60 | ||||||||
| exhoust m3/h | 10 | 20 | 25 | 60 | |||||||||
| pressure kpa | 60 | 60 | 60 | 60 | |||||||||
| speed r/min | 400 | 400 | 400 | 400 | |||||||||
| motor power kw | 0.37 | 0.75 | 1.1 | 2.2 | |||||||||
| Discharge pump | model | 25CGW-10-15 | 32CGW-15-20 | 40CGW-15-30 | 40CGW-15-30 | ||||||||
| capacitym3/h | 10 | 15 | 15 | 15 | |||||||||
| lift m | 15 | 20 | 30 | 30 | |||||||||
| speed r/min | 2840 | 2840 | 2840 | 2840 | |||||||||
| motor power kw | 1.1 | 1.5 | 2.2 | 2.2 | |||||||||
| discharge caliber mm | 25 | 32 | 40 | 40 | |||||||||
| Motor type | 3-phase AC380V/50Hz | ||||||||||||
| Control mode | Automatic and Manual | ||||||||||||
| Chemical consumption kg/d | 0.01 | 0.03 | 0.04 | 0.05 | 0.06 | 0.07 | 0.09 | 0.11 | 0.18 | 0.22 | 0.28 | 0.33 | |
| Quality of effluent | SS <50mg/L BOD <50mg/L Coliform <250pc/L Phvalue 6-9 | ||||||||||||
| Weight | Dry(T) | 0.85 | 1.1 | 1.34 | 1.5 | 1.65 | 1.9 | 2.45 | 3.1 | 5.1 | 6.4 | 7.4 | 8.4 |
| Wet(T) | 1.85 | 3.15 | 3.85 | 5.3 | 6.4 | 7.65 | 8.8 | 10.2 | 15.4 | 21.1 | 27.6 | 36.2 | |
| Dimension L*W*H(mm) | 1150 *1100 *1450 | 1500 *1200 *1760 | 1650 *1580 *1760 | 2000 *1680 *1870 | 2400 *1800 *1900 | 2550 *1950 *1900 | 2950 *2050 *1900 | 3300 *2050 *1900 | 3500 *2500 *2200 | 4300 *2700 *2200 | 4490 *2900 *2400 | 4900 *3150 *2400 | |
