Guangdong, China (Mainland)
DEYUAN MARINE
CXH1-3P
Starboard Light
Navigation Signal Light
Ships night navigation
CE / CCS
Red / Green / Yellow / White
25W
12V
B15d
IP56
0.5KGS
Standard Export Packing
7~10Days
Marine Navigation Signal Starboard Light
Marine Navigation Signal Starboard Light
The scope of application:
Applied to the ships with the length less than 12m as lamp signal liaison when night navigation.
Product characteristic:
1.The shell is made of high-strength engineering plastic PA+GF,the lampshade adopts injection of PC,lens hood adopts good quality stainless steel.
2.The signal lights have the whole seal structure,it is waterproof under the bad environment.
3.The signal lights choose the special signal bulb which conform to the ship criterion,can replace as open the cover.
4.The signal lights can work normally under the temperature -30℃~55℃.
Production authentication:
Approved by CCS(China Classification Society),and ZY of China Fishery Inspection.
Adopt standard:
1.Conform to the international regulations for preventings collision at sea,1972 and Grade entry norms for steel ships.
2.Confirm to the international standard IEC60598-1-2008.
3.Confirm to the standard of marine electric signal light's technical condition GB/T3028-2012.
Name | Type | Visibility | Level arc | Bulb | Protection class | Color | Weight |
Starboard light | CXH1-3P | 2 | 112.5° | 24V25W (B15d) | IP56 | Green | 0.5kg |
Port light | CXH2-3P | 2 | 112.5° | Red | 0.5g | ||
Masthead light | CXH3-3P | 5 | 225° | Transparent | 0.5kg | ||
Stern light | CXH4-3P | 2 | 135° | Transparent yellow | 0.5kg | ||
All-round light | CXH6-3P | 2 | 360° | Red green transparent | 0.5kg |
CXH1-3P Navigation Signal Starboard Light
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Tina Zhu
E-mail: sales5[at]deyuanmarine[dot]com
Skype: marinesales5
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: +86-13286053269
Web: http://www.deyuanmarine.com
