90KN Free Fall Lifeboat Davit

90KN Free Fall Lifeboat Davit



90KN Free Fall Lifeboat Davit

The design of the davit conforms to the requirements of the “1974 SLOAS [MSC.47(66)]

and International LSA Code [MSC.48(66)] , and also can be approved by Classification Society.

Scope of supply(one shipsets consisting of ):

1)A complete set of launching appliance :1set

2) A complete set of hydraulic winch:1set

3) Control panel of hydraulic system (IP56)  :1set

4) Control box :1set

5) Push button (IP56) :1set

6) Spare parts of hydraulic system :1set

7) Boat fall and all necessary rope :1set





*SWL:90KN



*Max. working load of davit: Max.90 kN



*Max. Hoisting load of davit:85 kN



*Boat hoisting speed: more than 3.0 m/min



* Power source: AC440V,60Hz,3φ







Name	Unit	Type/ Data
		55KN	70KN
Max. working load	KN	55	70
Max. hoisting load	KN	42	50
Hoisting speed of boat	M/min	>3	>3
Capacity of drum	M	45	45
Diameter of wire rope	mm	18	20
