1.15PPM Bilge Water Alarm
2.Measuring range: 0-30ppm (display range 0-80ppm).
3.Protection class IP55
15PPM Bilge Water Alarm
1) Measuring range: 0-30ppm (display range 0-80ppm).
2) Measurement precision: (15ppm alarm) ± 5ppm (meet the IMO standard).
3) Display type : LED digital tube.
4) 15ppm bilge water Alarm Alarm indication: 4 red LED.
5) 2-way alarm relay.
6) Rated capacity of relay contact 250VAC 3A (non-emotional).
7)Model:15ppm bilge alarm.
15ppm Bilge Water Alarm Main performance indicators:
1) Measuring range: 0-30ppm (display range 0-80ppm)
2) Measurement precision: (15ppm alarm) ± 5ppm (meet the IMO standard)
3) Display type : LED digital tube
4) 15ppm bilge water Alarm Alarm indication: 4 red LED
5) 2-way alarm relay
6) Rated capacity of relay contact 250VAC 3A (non-emotional)
7) 15ppm bilge water Alarm Response time ≤ 5 seconds
8) Output signal 4-20mA
9) Environment temperature 0 - 55 Celsius degree
10) bilge water Alarm Relative humidity≤ 93%
11) Sample liquid temperature 1 - 55Celsius degree
12) Sample liquid pressure 0.1-0.6MPa
13) Sample liquid flow of 0.1-4L / min
14) Protection class IP55
15) Main power supply 220/110VAC 50Hz/60Hz
16) Power Consumption ≤ 20VA
17) Overall dimension 400mm × 300mm × 160mm
18) Meet the standard IMO. Res. MEPC. 107 (49) resolution
China Deyuan Marine Fitting Co.ltd is a professional supplier of marine equipment,such as 15ppm bilge separator,15ppm oily water separator,15ppm bilge alarm,oil content meter,marine sewage treatment plant etc.Pls contact us for more details if you are interested.
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Kitty
E-mail: sales7[at]deyuanmarine[dot]com
Skype:marinesales6
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: + 86 - 13427793868
Web: http://www.deyuanmarine.com
