Marine Bronze Fuel Oil Tank Self-Closing Drain Valve JIS F7398U 5K

Inquire Add to Basket

  • DEYUAN

  • Standard

  • Control

  • Low Pressure, 5K/10K

  • Manual

  • Casting, Bronze

  • Normal Temperature

  • Water

  • 15-80

  • China (Mainland)

  • JIS F7398

  • DEYUAN

  • One Year

  • JIS F7398

  • plywood case

  • 20-60days according to the quantity

Specifications


Marine Drain Valve
1)good quality with test certificate
2).with one year's warranty
3)CCS,DNV, BV,ABS,RINA certificate



Marine Bronze Fuel Oil Tank Self-Closing Drain Valve JIS F7398U 5K

Design Standard: JIS F7398-1996

Test Standard: JIS 7400-1996

Hydraulic Test Pressure: Body-0.15Mpa, Seal-0.11Mpa

Flange size as per JIS B2220 - 5K



Main Material:

1.Body: Bronze (BC6)

2.Bonnet: Bronze (BC6)

3.Disc: Bronze (BC6)

4.Stem: Brass (C3771BD)

5.Lever: SS400

6.Gasket: non-asbestos



Main Size List(mm):

DN d L L1 D C NO. h t H
5K15U 15 55 55 80 60 4 12 9 179
5K20U 20 65 65 85 65 4 12 10 187
5K25U 25 65 65 95 75 4 12 10 187
5K40U 40 90 100 120 95 4 15 12 229
5K50U 50 115 130 130 105 4 15 14 252
5K65U 65 135 155 155 130 4 15 14 252
