Marine Can Water Filter JIS 7121 10K (DN25-DN100)

Brand:
DEYUAN
Standard or Nonstandard:
Standard
Structure:
strainer
Pressure:
Low Pressure, 5K/10K
Power:
Manual
Material:
Casting, Cast Iron
Temperature of Media:
Normal Temperature
Media:
Water
Port Size:
40-100
Place of Origin:
China (Mainland)
Model Number:
JIS F7121S
Brand Name:
OEM
Warranty:
one year
Standard:
JIS F7121
Packaging Details:
each piece with plastic bag, and the outside case is the plywood case.
Delivery Detail:
10-60days according to the quantity

Specifications

Marine Can Water Filter:
1)good quality with test certificate
2)with one year's warranty
3)stainless steel filter

Marine Can Water Filter JIS 7121 10K

Marine Can Water Filter JIS F7121 also can be called as marine sea water filter(strainer) or marine basket water filer(strainer).

Design Standard: JIS F7121-1996

Test Standard: JIS 7200-1996

Hydraulic Test Pressure: Body- 0.3Mpa

Flange size as per JIS B2220 - 10K

Type: S, LA, LB

Body: Cast Iron (FC200)

Bonnet: Cast Iron (FC200)

Strainer: Stainless Steel (SUS304)

Gasket: non-asbestos

Yoke: FCD450

Air Vent Plug: Brass

Drain Plug: Brass
