Marine Cast Iron Air Pipe Head (DN100-DN450)

Inquire Add to Basket

  • DEYUAN

  • Standard

  • Check

  • Low Pressure, 5K/10K

  • Air

  • Casting, Cast Iron

  • Normal Temperature

  • air

  • 100-450

  • China (Mainland)

  • JIS-KS91A-121

  • OEM

  • one year

  • JIS-KS91A-121

  • each piece with plastic bag, and the outside case is the plywood case.

  • 10-60days according to the quantity



Marine Cast Iron Air Pipe Head:

Air Vent Head also can be called as air pipe head, is used for the ventilation of the oil tank or water tank on the vessel.

Test Standard: JIS 7400-1996

Flange size as per JIS B2220 - 5K

* The flange size also can be manufactured according to 10K, 16K.



Main Material:

S/N Name Material S/N Name Material
1 Hex Bolt STS304 8 Screen Cover SS400
2 Cover SS400 9 Float Disc STS304
3 Packing NBR 10 Hex Bolt STS304
4 Body FC200,FCD450 11 Packing NBR
5 Hex Bolt STS304 12 Spring Washer STS304
6 Rubber Ring NBR 13 Guide Bolt STS304
7 Wire Screen STS304




Main Size List(mm):

Dimension (mm)
Weight (kgs)
DN D2 D3 HT H1 T N-d1 A A3 R
100 165 200 220 160 16 8-19 245 155 250 23
125 200 235 250 180 16 8-19 270 180 288 34
150 230 265 285 208 18 8-19 316 216 330 47
200 280 320 365 269 20 8-23 394 274 432 72
250 345 385 430 314 22 12-23 485 325 546 120
300 390 430 530 367 22 12-23 550 384 616 178
350 435 480 570 415 24 12-23 661 425 714 196
400 495 540 640 475 24 12-23 703 457 749 235
450 555 605 713 522 24 12-23 816 510 836 298
