Marine Cast Steel Quick Closing Valve JIS F7399 10K

  • DEYUAN

  • Standard

  • Shutoff

  • Low Pressure, 10K

  • Manual

  • Casting, Cast Steel

  • Normal Temperature

  • Oil

  • 40-150

  • China (Mainland)

  • JIS F7399

  • DEYUAN

  • One Year

  • JIS F7399

  • Manual Lever

  • plywood case

  • 10-60days according to the quantity



Marine Cast Steel Quick Closing Valve JIS F7399 10K:

Operation type: Manual (Lever) or Pneumatically operated

Design Standard: JIS F7399-1996

Test Standard: JIS 7400-1996

Hydraulic Test Pressure:Body- 0.7Mpa, Seat-0.2Mpa,Seal for quick closing-0.1Mpa

Flange size as per JIS B2220 - 10K



Main Material:

Body: Cast Steel (SC49)

Bonnet: Cast Steel (SC49)

Seat: Stainless Steel (SCS2)

Disc: Stainless Steel (SCS2)

Stem: Stainless Steel (SUS403)

Operation Spindle: SUS403

Operation Lever: SUS403

Handwheel: FC200 (Cast iron)



Main Size List(mm):

DN L L1 L2 D C No of bolt hole bolt hole diameter flange thickness H D2
40 170 85 80 140 105 4 19 16 310 140
50 220 125 90 155 120 4 19 16 335 160
65 270 155 100 175 140 4 18 18 395 180
80 300 165 120 185 150 8 19 18 420 180
100 350 200 130 210 175 8 20 18 510 224
125 420 250 160 250 210 8 19 20 440 250
150 490 300 180 280 240 8 19 22 520 320
