Electric Single Gyspy Mooring Winches/Marine Winch
China Deyuan Marine Fitting Co., Ltd is a professional supplier of marine winches,
we can offer mooring winches, anchor winches, accommodation ladder winches, rope ladder winches,
electric rescue boat winches, pneumatid rope ladder winch and other anchor windlass, capstan,
hydraulic steering gear. Pls contact us for more detials.
Mooring Winches Features:
1) Drive: Electric
2) Configuration: Horizontal arrangement
3) Rope drum: Steel wire rope
4) Rope speed: Complying with ISO requirements
5) Rate pull (1st layer): 130 Tonnes
5) Clutch: Electric operated
6) Brake: Electric operated band failsafe brake
7) Brake Holding: 1st layer static up to 200Tonnes or complying with ISO/ Classification Society requirement
8) Control: Local/ remote control
| Name | Rated pull(kn) | Rate speed (m/min) | Drum capacity (m) | Motor Power (kw) |
| 5KN electric mooring winch | 5 | ≥12 | Φ15*100 | 3/1.2 |
| 10KN electric mooring winch | 10 | ≥12 | Φ15*150 | 4.3/1.7 |
| 20KN | 20 | ≥12 | Φ15*150 | 8.5/3.5 |
| 30KN | 30 | ≥15 | Φ15*150 | 11/11/7.5 |
| 40KN | 40 | ≥15 | Φ17.5*150 | 16/16/11 |
| 50KN | 50 | ≥15 | Φ20.5*180 | 22/22/16 |
| 75KN electric mooring winch | 75 | ≥15 | Φ26*200 | 30/30/22 |
| 80KN | 80 | ≥12 | Φ26*200 | 30/30/22 |
| 100KN | 100 | ≥12 | Φ30*200 | 30/30/22 |
| 130KN electric mooring winch | 130 | ≥12 | Φ26*200 | 60/60/45 |
| 160KN | 160 | ≥12 | Φ30*250 | 60/60/45 |
| 200KN | 200 | ≥9.6 | Φ41*250 | 60/60/45 |
| 250KN | 250 | ≥9.6 | Φ44.5*250 | 75 |
| 315KN | 315 | ≥7.8 | Φ52*250 | 75 |
| 400KN | 400 | ≥7.8 | Φ56*250 | 90 |
| 500KN | 500 | ≥7.8 | Φ56*250 | 90 |
| 560KN | 560 | ≥6 | Φ56*250 | 90 |
| 600KN electric mooring winches | 600 | ≥6 | Φ56*250 | 110 |
| 650KN electric mooring winches | 650 | ≥6 | φ56*250 | 110 |
