2/3KN Marine Accommodation Ladder Winches for deck machinery

Availability:
  • Deyuan

Marine Accommodation Ladder Winch

Marine Accommodation Ladder Winch

1.Pneumatic rope ladder winch.

2.Rated load:2000N.

3.Support load:3000N.

4.Hoisting speed:4.8~25.5m/min.

Pneumatic rope ladder winch

The winch can be operated manually with a crank in case of an air failure.

Limit swithes are installed with the crank.As a

result,the air-resource can be automatically cut off when the crank is taken away and reconnected when

it's placed back  to its normal keep.

Rated load

2000N

Support load

3000N

Hoisting speed

4.8~25.5m/min

Capacity of wire

22m

Motor type

pending

Power

3.5ps

Rotate speed

1200r/min

Air press

0.5~0.7Mpa

Air consumption

3.5m3/min

Moving mode

manual
