Electric double mooring drum winch
*Rated pull:20KN.
*Rate speed:≥12(m/min).
*Drum capacity:Φ15*100m.
*Certificate:CCS,GL,ABS,BV,RINA,RS.
Electric double mooring drum winch
Drum load (KN) | Holding load (KN) | Power (kw) | Nom speed (m/min) | Rope dia. | Drum size(nylon wire size) | ||||
Nylon (mm) | Steel (mm) | D1 (mm) | D2 (mm) | L (mm) | Capacity (mm) | ||||
50 | 150 | 15 | 16 | 45 | 20.5 | 480 | 820 | 650 | 180 |
480 | 1045 | 720 | |||||||
80 | 240 | 15 | 25 | 50 | 26 | 480 | 880 | 820 | 200 |
480 | 1200 | 920 | |||||||
100 | 310 | 15 | 32 | 55 | 28 | 540 | 930 | 840 | 200 |
540 | 1260 | 840 | |||||||
125 | 360 | 15 | 38 | 64 | 30 | 540 | 950 | 820 | 200 |
540 | 1480 | 960 | |||||||
160 | 480 | 15 | 50 | 75 | 38 | 540 | 950 | 820 | 200 (250) |
540 | 1480 | 960 | |||||||
200/250 | 630 | 15/12 | 61 | 90 | 40 | 650 | 1150 | 1000 | 250 (240) |
650 | 1600 | 1400 | |||||||
