Marine electric lifeboat winch

Marine electric lifeboat winch



*.Item: Electric Life/rescue boat winch

* Working load:25KN~138KN.

* .Hoisting speed:≥36m/min.



This winch compiles with requirements of SOLAS new regulation,international life-saving appliance regulation MSC.48(66) international life –saving appliance test MSC.81(70) and the lifeboat/rescue boat winch technology performance requirements(ISO6067)



type	Working load	Hoisting load(kn)	Hoisting speed	Descending rope speed	motor
D25Z	25 KN	20KN	≥36	90-110	12.5/12.5
D40Z	40 KN	20 KN	≥36/10	80-90	16.8/16.8
D42Z	42 KN	21 KN	≥36/10	80-110	15
D50Z	50 KN	28 KN	≥36/10	≤78	20/7.5
D63Z	63 KN	30 KN	≥36/10	90-110	22.5/10.6
D100Z	100 KN	55/70 KN	≥36/8	90-120	42/20
PW100Z	100 KN	60/100 KN	≥18/8	50-60	22.5
PW138Z	138 KN	80/138 KN	≥18/8	40-60	30
