CXH6-1S
Other
Red, Green White
24V/60W60cd 110V/60W60cd 220V/65w60cd
P28S
IP56
3-6n.m
112.5-360 degree
11
CCS ABS CE BV etc
High
Exported packing
Export Standard
Single-Deck Stainless Steel Navigation Signal All-around Light
Single-Deck Stainless Steel Navigation Signal All-around Light
Application scope:
Used in ships with length 50m or above 50m as lamp signal liasion when night navigation.
Product characteristics:
1.The shell adopts good quality stainless steel plate. The surface is painted with special mold powder, has the feature of corrosion
resisting and shock resistance.
2.Whole seal structure, waterproof under severe environment.
3.It is convenient to replace the bulb due to the quick-open cover.
4.The lampshade adopts PC material, chroma stable and ultraviolet radiation resistance.
Certificates:
Approved by CCS (China Classification Society), ZY of China Fishery Inspection.
Standard:
1.Conform to THE INTERNATIONAL REGULATION FOR PREVENTINGS COLLISION AT SEA, 1972 and GRADE ENTRY
NORMS FOR STEEL SHIPS.
2. Conform to the standard of marine electric signal light's technical condition GB/T 3028-2012.
Name | Type | Visibility | Level arc | Lamp holder | Bulb | Protection class | Cable outside diameter | Color |
Starboard light | CXH1-1S | 3n.m | 112.5° | P28S |
24V/60W60cd 110V/60W60cd 220V/65w60cd | IP56 | Φ11 | Green |
Port light | CXH2-1S | 3n.m | 112.5° | Red | ||||
Masthead light | CXH3-1S | 6n.m | 225° | White | ||||
Stern light | CXH4-1S | 3n.m | 135° | White Yellow | ||||
All-round light | CXH6-1S | 3n.m | 360° | Red, Green White |
CXH6-1S Single-Deck Stainless Steel Navigation Signal All-around Ligh
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Wenky
E-mail: sales10[at]deyuanmarine[dot]com
Skype: marinesales10
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: +86 - 13798955776
Web: http://www.deyuanmarine.com
Single-Deck Stainless Steel Navigation Signal All-around Light
Single-Deck Stainless Steel Navigation Signal All-around Light
Application scope:
Used in ships with length 50m or above 50m as lamp signal liasion when night navigation.
Product characteristics:
1.The shell adopts good quality stainless steel plate. The surface is painted with special mold powder, has the feature of corrosion
resisting and shock resistance.
2.Whole seal structure, waterproof under severe environment.
3.It is convenient to replace the bulb due to the quick-open cover.
4.The lampshade adopts PC material, chroma stable and ultraviolet radiation resistance.
Certificates:
Approved by CCS (China Classification Society), ZY of China Fishery Inspection.
Standard:
1.Conform to THE INTERNATIONAL REGULATION FOR PREVENTINGS COLLISION AT SEA, 1972 and GRADE ENTRY
NORMS FOR STEEL SHIPS.
2. Conform to the standard of marine electric signal light's technical condition GB/T 3028-2012.
Name | Type | Visibility | Level arc | Lamp holder | Bulb | Protection class | Cable outside diameter | Color |
Starboard light | CXH1-1S | 3n.m | 112.5° | P28S |
24V/60W60cd 110V/60W60cd 220V/65w60cd | IP56 | Φ11 | Green |
Port light | CXH2-1S | 3n.m | 112.5° | Red | ||||
Masthead light | CXH3-1S | 6n.m | 225° | White | ||||
Stern light | CXH4-1S | 3n.m | 135° | White Yellow | ||||
All-round light | CXH6-1S | 3n.m | 360° | Red, Green White |
CXH6-1S Single-Deck Stainless Steel Navigation Signal All-around Ligh
