Deyuan Marine
1)Product:external fire pump for fifi system/Fire pump for fire fighting system
2)Type: Horizontal mounted single,centrifugal pump
3)Capacity:300M3/H
4)Certificate:CCS,RINA,ABS,GL,LR,RMRS etc
5)Model:SSCXB200-150
6)Brand:Deyuan Marine
7)Fit with CUMMINS ENGINE OR CAT Engine Or Weichai engine
*Fire PumpType: Horizontal mounted single stage double side suction,
top discharge centrifugal pump
*Medium: Water &seawater
*Fire PumpWorking Temperature: 32°C
*External fire pump Capacity: Q=300m3 /h
*External fire pump Throw head: H=130m
*Speed: 1800r/min
*Shaft: 174KW
*Inlet dimension: DN200
Outlet dimension: DN150
Material:
Case: Ductile iron
Impeller: Nickle-Al bronze
Shaft: Stainless steel
Sealing: Soft material
