dCZH202-1 Marine Explosion-proof Socket

dCZH202-1 Explosion-proof Socket

dCZH202-1 Explosion-proof Socket

Application:

Fit for electric appliances connecting and circuit breaking in ships, sea petroleum, chemical industry site etc.

Products characteristic:

The shell adopts precision brass casting, it has the feature of fine sealing function and fine electric function.

Production authetication:

This series of products have passed the Examination of National Explosion proof Electrical Test Center, and was approved by “CCS”(China classification society).

Adopt standard:

IEC60079



Code	5516/L	5516/R	5516/D
Type	DCZH202-1	DCZH202-2	DCZH202-3
Voltage	250V/16A
Explosion proof mark	Exde II C T6
Protection class	IP56
Material	Brass
Size	148mm*114mm*90mm
Weight	2.6kg	2.6kg	2.7kg



dCZH202-1 Explosion-proof Socket
