100KGS to 25000KGS AC-14 HHP Anchor





AC-14 HHP Anchor



AC-14 HHP Anchor is High Holding Power Stockless Anchor,  widely used as Bow Anchor and one of most popular anchor used in New Ship, Ship Repair and Stock.



Advantage:



High Holding Power

Good Stability

Easy Handling

One-stop Service, Fast Delivery.



Size Table



Nominal Weight (kg)	Dimensions (mm)
	A	B	C	D	E	F
970	1,592	1,445	440	978	292	775
1,080	1,650	1,495	455	1,014	302	805
1,200	1,710	1,545	470	1,050	315	835
1,305	1,760	1,595	485	1,082	323	858
1,361	1,782	1,615	495	1,096	326	870
1,440	1,818	1,645	505	1,118	332	885
1,575	1,875	1,695	518	1,152	343	915
1,710	1,925	1,745	532	1,184	352	940
1,845	1,975	1,785	546	1,215	362	965
1,980	2,020	1,830	560	1,242	370	985
2,100	2,065	1,865	570	1,268	377	1,005
2,295	2,130	1,920	588	1,310	385	1,035
2,475	2,175	1,970	602	1,340	395	1,062
2,655	2,225	2,018	615	1,368	408	1,085
2,794	2,265	2,055	625	1,393	415	1,105
3,040	2,320	2,100	640	1,424	426	1,130
3,550	2,455	2,225	680	1,508	450	1,198
3,670	2,480	2,248	688	1,525	455	1,210
3,940	2,540	2,300	705	1,562	465	1,240
4,500	2,655	2,405	735	1,632	485	1,295
4,840	2,720	2,465	755	1,670	500	1,330
5,175	2,785	2,520	770	1,710	510	1,358
5,610	2,858	2,590	790	1,758	523	1,396
6,000	2,922	2,646	810	1,796	535	1,426
6,450	2,995	2,712	830	1,840	548	1,462
6,900	3,062	2,775	848	1,884	560	1,496
7,350	3,126	2,832	866	1,923	572	1,526
7,800	3,190	2,890	884	1,962	584	1,558
8,300	3,256	2,950	902	2,002	596	1,590
8,700	3,308	2,996	916	2,034	605	1,614
9,300	3,382	3,064	936	2,080	619	1,652
9,675	3,425	3,104	948	2,108	627	1,674
9,900	3,452	3,128	956	2,124	632	1,686
10,500	3,523	3,192	976	2,166	645	1,720
11,100	3,589	3,252	994	2,207	657	1,752
11,700	3,650	3,308	1,010	2,245	668	1,782
12,300	3,712	3,364	1,028	2,283	680	1,812
12,900	3,772	3,418	1,044	2,320	690	1,842
13,500	3,830	3,470	1,060	2,355	700	1,870
14,100	3,885	3,520	1,076	2,389	710	1,896
14,700	3,940	3,570	1,090	2,423	721	1,924
15,400	4,002	3,626	1,108	2,461	732	1,954
