DEYUAN MARINE
TFT
navigation sounder
500W
200KHz
20m
10m
Standard Export Packing
7~15 Days
10Inch TFT Navigation Sounder
*Digital signal processing
*20Hours recording
*Power protection and alarm
*Dual-channel &dual-frequency selection
Navigational Sounder | |
Item | Specification |
Graphical Display | 10inch color TFT LCD 640*480 pixels |
AC Adapter | AC220/110V |
DC Supply | DC24V |
Unit Weight | 3.7kg (Operation Unit) |
Dimension | 264(H)x270(W)X93(D)mm |
Frequency | 200KHz |
Power Output | 500W |
Depth Range | Smaller range scope:0-500m |
Larger range scope:0-800m | |
Accuracy | ±1.0% of range |
Histroy storing | 20hours history data |
Auto range | yes |
Draft Preset | 20m |
Shallow Alarm | 10m |
Power Alarm | Power Lost Alarm |
Alarm Media | Buzzer,Flashing |
Time Scale | 30s interval time bar on LCD |
Picture speed | 6steps plus freeze |
Ping Rate | Max 10pings per second |
Echo Color | 7colors |
NMEA Input | GPS Position(GGA) |
NMEA Output | Depth(DPT) |
Temperature | -10--40°C(IEC60945) |
Unit Protection | IP23(IEC60529) |
Funtion | Over voltage/current,Polarity |
Mounting | Desk/Ceiling/Flush mounting |
Transducer | 600W 200kHz6° |
Printer Type | DPU-414 |
Printer Interface | Serial Port |
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Tina Zhu
E-mail: sales5[at]deyuanmarine[dot]com
Skype: marinesales5
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: + 86 - 13286053269
Web: http://www.deyuanmarine.com
