Guangdong, China (Mainland)
DEYUAN MARINE
JCY23-2EF
Other
110V/60Hz 220V/50Hz 220V/60Hz
G13
IP55
6.3KG
2*20W
Deyuan
CCS ABS GL
Exported packing
Export Standard
2*20W IP55 Waterproof Fluorescent Pendant Lamp
The scope:
Fit for illumination of water dripping,water spattering,water coagulating place in ships,such as oven cabin,tunnel,pipeline
and weather deck etc.
Products characteristic:
1.The shell adopts good quality steel plate tensioned,lampshade adopts injection of PC,and has the seal structure.
2.In order to prevent from electric shocking,equipped with a copper earthing rod with the mark in and out the lights.
3.Plug in type lamp holder,equipped wiring terminal inside,convenient to connect.
4.The lamp equipped B15 lamp holder,used for 24V/15W emergency bulb,the edge of lampshade marks the marking,remark
clear that need
the emergency device when order.
5.Equipped compensating capacitance inside the lamp,also has the good effect of start.
Adopt standard:
Conform to CB/T3857-1999 standard
Type | Power | Voltage | Power factor | Lamp holder | Cable outside diameter | Protection class | Weight | Remark |
JCY23-2EF | 2*20W | 110V/60Hz 220V/50Hz 220V/60Hz | >0.85 | G13 | Φ12-Φ16 | IP55 | 6.3Kg | With emergency and mesh coer |
JCY23-2EF Fluorescent Pendant Light
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Wenky
E-mail: sales10[at]deyuanmarine[dot]com
Skype: marinesales10
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: +86 - 13798955776
Web: http://www.deyuanmarine.com
