DY
Deyuan
China
CCS, Gl, Dnv, ABS
ABS, GL, DNV, BV, CCS
Size of doorway B*L*R | Theoretical size of door sheet B1*L1*R1 | Hole size of Casting wall B2*L2*R2 | Outline size of door frame B3*L3*R3 | Position size of hinge and handle | Quantity of handles |
500*1000*100 | 540*1040*120 | 580*1080*140 | 654*1154*177 | 300 | 4 |
500*1200*100 | 540*1240*120 | 580*1280*140 | 654*1354*177 | 400 | 5 |
500*1400*100 | 540*1440*120 | 580*1480*140 | 654*1554*177 | 500 | 5 |
600*1200*100 | 640*1240*120 | 680*1280*140 | 754*1354*177 | 400 | 5 |
600*1400*100 | 640*1440*120 | 680*1480*140 | 754*1554*177 | 500 | 5 |
650*1600*100 | 690*1640*120 | 730*1680*140 | 804*1754*177 | 600 | 5 |
Size of doorway B*L*R | Theoretical size of door sheet B1*L1*R1 | Hole size of Casting wall B2*L2*R2 | Outline size of door frame B3*L3*R3 | Position size of hinge and handle | Quantity of handles |
500*1000*100 | 540*1040*120 | 580*1080*140 | 654*1154*177 | 300 | 4 |
500*1200*100 | 540*1240*120 | 580*1280*140 | 654*1354*177 | 400 | 5 |
500*1400*100 | 540*1440*120 | 580*1480*140 | 654*1554*177 | 500 | 5 |
600*1200*100 | 640*1240*120 | 680*1280*140 | 754*1354*177 | 400 | 5 |
600*1400*100 | 640*1440*120 | 680*1480*140 | 754*1554*177 | 500 | 5 |
650*1600*100 | 690*1640*120 | 730*1680*140 | 804*1754*177 | 600 | 5 |
