Marine Hydraulic Sliding Watertight Door Dy190107

Inquire Add to Basket

  • DY190107

  • Swing

  • Security

  • CCS, Gl, Dnv, ABS

  • ABS, GL, DNV, BV, CCS

  • Aluminum Alloy

  • Finished

  • Ship

  • Deyuan

  • China


1.Type:marine hydraulic sliding watertight door.
2.This product applies to watertight gateways of engine room below waterline of ships and meets the regulations for the classification and construction of sea-going steel ships in 1987.
This product can be hand operated on both sides of the engine room,it is designed for three-directional operation of hydraulic piping.
Marine hydraulic sliding watertight door
China Deyuan Marine Fitting Co.,ltd are leading supplier of marine outfitting equipment,such as marine steel doors,marine aluminum door,marine windows,marine hatch cover,marine pilot rope ladder,embarkation rope ladder,gangway ladder ,bulwark ladder etc.
This product applies to watertight gateways of engine room below waterline of ships and meets the regulations for the classification and construction of sea-going steel ships in 1987.
This product can be hand operated on both sides of the engine room,it is designed for three-directional operation of hydraulic piping.


Size of doorway
b*h		 Opening size
Of bulkhead		 B H L1 L2 Weight
(kg)
500*1000 532*1048 1230 1216 ~295 ~334 711.5
600*1200 632*1248 1480 1416 ~295 ~354 820.6
700*1400 732*1448 1700 1616 ~295 ~363 1063.8
