Quick-Opening-Closing Watertight Steel Door/Marine Watertight Door

Inquire Add to Basket

  • DY7282920

  • Deyuan

  • China

  • CCS, Gl, Dnv, ABS

  • ABS, GL, DNV, BV, CCS

Quick-Opening-Closing Watertight Steel Door/Marine Watertight Door:

1. Type: Quick-opening-closing watertight steel door
2. Material: Steel&aluminum

China Deyuan Marine Fitting Co., Ltd is a leading supplier of marine outfitting equipment, such as marine steel doors, marine aluminum door, marine windows, marine hatch cover, marine pilot rope ladder, embarkation rope ladder, gangway ladder etc.
This product applies to aluminum door on casting walls of military and merchant ships, also applies to others
Code of
standard		 Size of doorway
H*W*R		 Size of door
(H1*W1*R1)		 Hole size of casting wall
(H2*W2*R2)		 Thickness of
door sheet		 Weight
(kg)
1050 1000*500*100 1049*549*124.5 1100*600*150 6 92.3


1050*551*125.5
8 103.8
1260 1200*600*100 1249*649*124.5 1300*700*150 6 113.4


1251*651*125.5
8 129.0
1460 1400*600*100 1449*649*124.5 1500*700*150 6 128.6


1451*651*125.5
8 146.7
1475 1400*750*100 1449*799*124.5 1500*850*150 6 144.4


1451*951*125.5
8 165.9
1490 1400*900*100 1449*949*124.5 1500*1000*150 6 160.1


1451*951*125.5
8 185.2
1660 1600*600*100 1649*649*124.5 1700*700*150 6 136.9


1651*801*125.5
8 154.8
1675 1600*750*100 1649*799*124.5 1700*850*150 6 161.4


1651*951*125.5
8 185.7
1690 1600*900*100 1649*949*124.5 1700*1000*150 6 178.0


1651*951*125.5
8 206.4
Quick-Opening-Closing Watertight Steel Door/Marine Watertight Door
Quick-Opening-Closing Watertight Steel Door/Marine Watertight Door
Quick-Opening-Closing Watertight Steel Door/Marine Watertight Door
