12V
CE, ISO9001:2000, RoHS, CCS
5 - 10A
> 4500GPH
20-30
standard export wooden cases packing or as required
CS series Marine Used Hand Pump For Sale
*Competitive price.
*Complete model.
*ISO9001:2000.
*short delivery time.
This product is of double-acting reciprocating piston structure,suitable for delivery of fresh water,fuel sewage and non-corrosive
liquids.It is not suitable for the liquids containing fibers or other solid granules.
Y type in the CCS series pumps are used to draw oils or freshwater:Y type in the CS series pumps are used to draw seawater.
I,III series hand pumps are used to draw freshwater.
Type | Main technical parameter | |||||
Capacity (L/min) | Pressure head(m) | Recipro-cation (1/min) | Suction head (m) | Cylinder diameter (mm) | Piston stroke(mm) | |
CS-20 | 20 | 20-25 | 50 | 5 | 65 | 68 |
CS-20Y,CS-20H | 20 | 25 | 50 | 6 | 65 | 68 |
CS-25Y, CS-25H | 32 | 25 | 50 | 6 | 75 | 80 |
CS-32 | 40 | 20-25 | 50 | 5 | 88 | 90 |
CS-32Y CS-32H | 48 | 25 | 50 | 6 | 88 | 90 |
CS-40Y CS-40H | 65 | 25 | 50 | 6 | 95 | 96 |
I | 20 | 30 | 80 | 5 | 65 | 50 |
III | 65 | 30 | 52 | 5 | 100 | 68 |
CS Series Marine Hand Pump
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Wenky
E-mail: sales10[at]deyuanmarine[dot]com
Skype: marinesales10
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: +86 - 13798955776
Web: http://www.deyuanmarine.com
